Semicircular-Half Round Glass Clamp

Glass Clamps:

• 789000 Glass clamp semicircular, connection straight V2A, polished
• 789424 Glass clamp semicircular, tube Ø 42.4 mm V2A, polished
• 789483 Glass clamp semicircular, tube Ø 48.3 mm V2A, polished



Rubber Insert:

• 971276 Rubber insert, set glass 12,76 mm EPDM

Technical Characteristics:

Product Code	789000	789424	789483
Material	AISI 304	AISI 304	AISI 304
Surface	satin	satin	satin
Type	Half round	Half round	Half round
Measures	43 x 64 mm	43 x 64 mm	43 x 64 mm
Glass Thickness	-	-	-
Pipe fitting	Straight	Ø 42,4 mm	Ø 48,3
Details	A=43; B=64; C=26; D=16	A=43; B=64; C=26; D=16	A=43; B=64; C=26; D=16
